Vom Marktführer im Bereich Spaltlampen-Imaging
Spaltlampen-Bildgebung
Professionelle Spaltlampen für jeden Bedarf.
Durch langjährige Erfahrung in der Spaltlampenfotografie bieten wir maßgeschneiderte und nahtlose Imaging-Lösungen für Haag-Streit Spaltlampen an.
Compare our products
Imaging Modul 910 | 3D Option | Imaging Module 600 | Imaging Set BI 900 | |
---|---|---|---|---|
Compatibility | ||||
BQ 900 | ● | ● | ● | − |
BP 900 | − | − | ● | − |
BI 900 | − | − | − | ● |
Beam path | ||||
Right side | ● | ● | ● | − |
Left side | − | ● | − | ● |
Control panel | ||||
RM03 | ● | ● | − | − |
RM02 | − | − | ● | ● |
Dept of focus control | ||||
Adjustable aperture | ● | ● | − | − |
Fixed aperture | − | − | ● | ● |
Camera interface | ||||
CoaXPress | ● | ● | − | − |
USB 3.0 | − | − | ● | ● |
Shutter system | ||||
Global shutter | ● | ● | ● | ● |
Frame rate | ||||
Max. 30 fps | ● | ● | ● | ● |
Operation mode | ||||
Standalone mode | ● | ● | − | − |
EyeSuite mode | ○ | ○ | ● | ● |
Software | ||||
EyeSuite Imaging | ○ | ○ | ● | ● |
EMR interfaces | ||||
EyeSuite script language | ● | ● | ● | ● |
DICOM (SCU) | ● | ● | ● | ● |
GDT | ● | ● | ● | ● |
Samba Share for direct import into patient file | ● | ● | − | − |
Connector box | ||||
CB01 | ● | ● | − | − |
CB01 connectivity | HDMI out, DisplayPort out, Ethernet | HDMI out, DisplayPort out, Ethernet | − | − |
● standard | ○ optional | − not available | □ not recommended
